Fast Blow Axial Radial Resistance Fuses
Specifications
Rated voltage: 250VAC
Rated current: 50mA~15A
Breaking capacity: 50A@250V AC
Product Certification: UL
Standard
·UL248-1
·UL248-14
Product features
·Designed to UL248 Standard
·Fast blow,ceramicbody fuse
·RoHS compliant and lead-free
·This space saving fuse is ideally suited for lighting, power supply, and adapter applications
·Available in axial lead format
Applications
·Consumer Electronics
·Power Supply & Lighting
·Home Appliances
·Communications & Networks
·Industrial & Instrumentation
·Automotive Electronics
·Specialty or Professional Fields
ProductSize(mm)
Material Details
|
NO. |
Part Name |
Material |
|
① |
Cap |
Nickel Plated Brass |
|
② |
Body |
Ceramic tube |
|
③ |
Fuse element |
Alloy |
|
④ |
Coat |
Epoxy green |
ProductParameters
|
Part No |
Rated current |
Rated voltage
|
Breaking capacity
|
I²T A²s |
Safety Approvals |
|
|
|
|
|||||
|
2F0050 |
50mA |
250V |
50A @250V AC
|
0.00025 |
● |
● |
|
2F0062 |
62mA |
0.00029 |
● |
● |
||
|
2F0080 |
80mA |
0.00066 |
● |
● |
||
|
2F0100 |
100mA |
0.0009 |
● |
● |
||
|
2F0125 |
125mA |
0.0056 |
● |
● |
||
|
2F0160 |
160mA |
0.003 |
● |
● |
||
|
2F0200 |
200mA |
0.03 |
● |
● |
||
|
2F0250 |
250mA |
0.049 |
● |
● |
||
|
2F0315 |
315mA |
0.049 |
● |
● |
||
|
2F0400 |
400mA |
0.081 |
● |
● |
||
|
2F0500 |
500mA |
0.226 |
● |
● |
||
|
2F0630 |
630mA |
0.056 |
● |
● |
||
|
2F0800 |
800mA |
0.098 |
● |
● |
||
|
2F1100 |
1.0A |
0.3 |
● |
● |
||
|
2F1125 |
1.25A |
0.5 |
● |
● |
||
|
2F1160 |
1.6A |
0.8 |
● |
● |
||
|
2F1200 |
2.0A |
1.2 |
● |
● |
||
|
2F1250 |
2.5A |
2.0 |
● |
● |
||
|
2F1300 |
3A |
2.5 |
● |
● |
||
|
2F1315 |
3.15A |
2.9 |
● |
● |
||
|
2F1400 |
4.0A |
4.2 |
● |
● |
||
|
2F1500 |
5.0A |
7.2 |
● |
● |
||
|
2F1630 |
6.3A |
12 |
● |
● |
||
|
2F1800 |
8.0A |
20.23 |
● |
● |
||
|
2F2100 |
10.0A |
33.28 |
● |
● |
||
|
2F2120 |
12.0A |
35.26 |
● |
○ |
||
|
2F2125 |
12.5A |
40.06 |
● |
○ |
||
|
2F2150 |
15.0A |
83.43 |
● |
○ |
||
Note: ●Denotes for certification approved ; ○Denotes for pending certification
